Solidworks PDM二次开发—文件夹相关操作

前言

好久没有更新Solidworks PDM的操作了，今天我们来学习一下文件夹的几个常用操作。

新建文件夹

可以参考api中的帮助 Add Folder Example (C#) —这里面有相关的卡设置

               //new 一个库对象
                var vault = new EdmVault5();

                //登陆到库中
                vault.LoginAuto("PDM2020Default", this.Handle.ToInt32());

                var vault2 = (IEdmVault7)vault;

                //本地根目录
                var rootPath = vault2.RootFolderPath;


                var rootFolder = vault2.RootFolder;

                //新建子文件夹
                //这里路径可以多个子层级 如A\B\C

                var newFolder = rootFolder.CreateFolderPath($@"\newTempFolder", this.Handle.ToInt32());

 IEdmFolder5 parentFolder = default(IEdmFolder5);
                parentFolder = vault2.GetFolderFromPath(ListBox.Items[0].ToString());

                dynamic folderName = "Temp";
                IEdmUserMgr5 usrMgr = default(IEdmUserMgr5);
                usrMgr = (IEdmUserMgr5)parentFolder.Vault;

                EdmFolderData data = default(EdmFolderData);
                data = new EdmFolderData();

                data.SetUserRights(usrMgr.GetUser("Engineer1").ID, (int)EdmRightFlags.EdmRight_Read | (int)EdmRightFlags.EdmRight_Lock);
                data.SetGroupRights(usrMgr.GetUserGroup("Administrators").ID, (int)EdmRightFlags.EdmRight_All);

                IEdmCard5 card = default(IEdmCard5);
                card = parentFolder.Vault.RootFolder.GetCard("doc");
                data.SetCardSource(card.ID, "doc");

                IEdmFolder5 folder = default(IEdmFolder5);
                folder = parentFolder.AddFolder(this.Handle.ToInt32(), folderName, data);
                Interaction.MsgBox("Created " + folderName + " successfully with ID, " + Conversion.Str(folder.ID) + ", in " + parentFolder.Name);

获取文件夹对象

 	            //读取文件夹

                //var tempFolderObj = vault2.GetFolderFromPath($@"文件夹路径");


                IEdmEnumeratorVariable6 EnumVarFolder = (IEdmEnumeratorVariable6)folderObj;

                object ResValueObjFolder = null;
                //object ResValueObjFolderDB = null;
                //从数据库中读
                //EnumVarFolder.GetVarFromDb("项目编号", "", out ResValueObjFolderDB);

                EnumVarFolder.GetVar("项目编号", "", out ResValueObjFolder);
                if (ResValueObjFolder != null)
                {
                    MessageBox.Show($"项目编号:" + ResValueObjFolder);
                }

删除文件夹

 			//删除文件夹 DeleteFolder Method (IEdmFolder5)

                rootFolder.DeleteFolder(this.Handle.ToInt32(), folderObj.ID, true);

刷新文件夹

     			//刷新本地文件夹

                rootFolder.Refresh();

结果正常:

结束，收工。
